| Brand Name: | Lingyao |
| Model Number: | LY120A |
| MOQ: | 1 unit |
| Price: | USD 5,000-50,000 per unit |
| Payment Terms: | D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 10 pcs per month |
Higher quality and Complicance High speed Lingyao LY120A heat sealing machine
500×400mm mould size heat sealing machine lead a higher quality and Complicance
Quality: The heat sealing process provided by this machine can create strong and reliable seals, crucial for maintaining the quality and integrity of medical products.
Compliance: Many medical packaging standards require specific seal widths and strengths, which can be easily achieved with a machine of this size.
Overall, the 500×400mm mould size heat sealing machine is well-suited for the medical industry due to its precision, efficiency, versatility, quality of seals, and compliance with industry standards.
The 5-25 times per minute cutting frequency heat sealing machine for the medical industry offers several advantages:
Precision and Accuracy: The machine's ability to operate at a specific cutting frequency allows for precise and accurate sealing, ensuring that each package is sealed correctly and securely.
Versatility: With a range of cutting frequencies from 5 to 25 times per minute, the machine offers versatility in accommodating different types of packaging materials and sizes, making it suitable for a variety of medical products.
Cost-Effectiveness: The machine's high cutting frequency can lead to cost savings in terms of time and labor, as it can handle a larger volume of packaging in a shorter period, increasing efficiency and reducing production costs over time.
| Model | LY-120A |
| Cutting Frequency | 5-25 times/min |
| Tooling layout | according to product size |
| Tooling max size | 500mm X 400mm |
| PET thickness | 0.3mm-1.0mm |
| Dialysis Paper | 50-100g x 620 |
| Air pressure and consumption | 0.6-0.8 Mpa/10-20 cbm/hour |
| Voltage/Frequency | 220V/50Hz |
| Total Power | 5KW |
| Machine Size | 1200mm x 800mm x 1650mm |
| Weight | 500 KGs |
The Tyvek heat sealing machine works by using heat and pressure to seal Tyvek material, which is a type of high-density polyethylene (HDPE) material made by DuPont. Here is a general overview of how a Tyvek heat sealing machine typically works:
Preparation: The Tyvek material to be sealed is placed between the sealing bars of the machine.
Heating: The machine heats the sealing bars to a specific temperature suitable for sealing Tyvek material. The heat softens the material, allowing it to bond together when pressure is applied.
Pressure: The sealing bars come together under pressure, pressing the heated Tyvek material together to create a strong seal.
Cooling: After the sealing process is complete, the sealed Tyvek material is allowed to cool down and solidify, ensuring a secure bond.
Trimming: In some cases, the excess material may be trimmed off to create a clean and neat seal.
Quality Check: The sealed Tyvek material may undergo a quality check to ensure that the seal is strong, secure, and meets the required specifications.
Overall, the Tyvek heat sealing machine combines heat and pressure to effectively seal Tyvek material, creating airtight and secure seals for various applications, including medical packaging, protective clothing, and other industries.
