Executive Summary

In the global pharmaceutical and health product industries, oral liquid manufacturing faces the dual challenges of aseptic assurance and high-volume efficiency. The LYYGZ5-25 Linkage Production Line, specifically engineered for 5–25ml straight-tube bottles, represents a benchmark in automated mechatronics. By integrating ultrasonic cleaning, high-temperature sterilization, and precision filling-capping into a single continuous workflow, this system offers a "Turnkey" solution that is compliant with GMP and cGMP standards.

1. Core System Architecture and Process Workflow

The LYYGZ5-25 linkage line consists of four primary technical modules, achieving a fully automated transition from raw containers to finished products:

1.1 Precision Washing: Vertical Ultrasonic Washing Machine

Cleaning is the critical first step in ensuring a sterile product.

• The system utilizes a combination of online ultrasonic cleaning and independent, alternating water and air jets.

• This method effectively removes micro-particles from the bottle interior, ensuring high clarity and a superior qualified rate for visible foreign matter detection.

• The specialized bottle-clamping mechanism significantly reduces the breakage rate to ≤0.5%.

1.2 Sterilization: Tunnel-Type Hot Air Circulation Oven

Washed bottles enter the oven directly to undergo high-speed sterilization.

• Based on the laminar flow principle, containers pass through preheating, drying/sterilization, and cooling phases within a sealed tunnel.

• The process is completed under Class-A standard laminar flow conditions, ensuring containers are totally sterile before entering the filling zone.

1.3 Aseptic Filling and Sealing: Oral Liquid Filling & Capping Machine

This core module features a "positive table" (balcony) design for enhanced hygiene.

• Filling System: Equipped with high-precision peristaltic or ceramic pumps. The needles utilize a reciprocating tracking system to ensure no leakage or foaming during high-speed operation.

• Sealing System: Employs a single-knife follow-up or three-knife capping principle. The adjustable blades ensure each seal is tight and smooth without damaging the glass.

• Intelligent Sensors: Integrated sensors facilitate "No Bottle, No Filling" and "No Bottle, No Capping" protocols to prevent material waste.

2. Key Technical Specifications

The professional parameters of the LYYGZ5-25 series reflect its industrial-grade performance:

3. Global GMP Compliance and 2026 Competitive Advantages

Designed with an advanced philosophy, the LYYGZ5-25 meets the stringent requirements of international pharmaceutical regulators:

• Material Integrity: The entire line is constructed from high-quality SUS304/SUS316L stainless steel. All parts in contact with medicine are made of non-toxic, medical-grade sanitary materials.

• Contamination Control: The integrated linkage drastically reduces secondary contamination risks associated with manual handling.



• International Service: Suzhou Lingyao has extensive experience exporting to Europe, India, Southeast Asia, and Russia. We provide comprehensive overall logistics and workshop planning to help manufacturers maximize their production quality.

4. Conclusion

The LYYGZ5-25 Linkage Line is the culmination of Suzhou Lingyao's expertise in pharmaceutical equipment. By balancing high-speed production with sterile integrity and intelligent automation, it empowers manufacturers to meet the world’s rising health standards.

Model Focus: LYDG-2 Eye Drop Filling-Plugging-Capping Integrated Machine

1. Executive Summary

In the pharmaceutical industry, ophthalmic products (eye drops) require the highest level of sterility and dosage accuracy. The LYDG-2 system is a mechatronics high-tech solution designed specifically for the 5–20ml bottle range. By integrating bottle unscrambling, filling, plugging, and capping into a single automated unit, this machine minimizes human intervention and environmental exposure, ensuring full compliance with GMP and cGMP standards.

2. Integrated Architectural Design

The core strength of the LYDG-2 lies in its integrated structural design. Consolidating multiple packaging stages into one machine significantly reduces the contamination risks associated with intermediate bottle transfer.

• Sterile Filling Zone: The system can be equipped with a 100-level laminar flow hood to maintain a Class-A sterile environment during the filling process.

• Safety Protocols: Advanced sensors ensure a "No Bottle, No Filling" and "No Bottle, No Plug/Cap" operation, preventing resource waste and maintaining a clean work environment.

• Mechanical Reliability: The machine utilizes mechanical transmission, which provides more accurate and stable movement compared to pneumatic systems, with the added benefit of being noise-free and air-pollution-free.

3. Core Technical Specifications

The LYDG-2 is engineered for medium to small batch production with high efficiency and minimal material loss.

4. Material Integrity and Hygiene

To meet global pharmaceutical standards, all components of the Lingyao eye drop line are built for durability and sanitation:

• Contact Parts: All parts that come into contact with the liquid medicine are made of medicinal hygienic materials.

• Surface Protection: The workbench and frame are protected with high-quality stainless steel (SUS304), facilitating easy cleaning and sterilization.

5. End-to-End Line Integration

For a complete "Turnkey" solution, the LYDG-2 integrates seamlessly with downstream equipment to form a full production line:

1. Labeling (LYLTJ): High-speed vertical self-adhesive labeling with an accuracy of ±0.5mm.

2. Cartoning (LYZHJ-120K): Specifically designed for oral/injection liquids, it handles manual folding, batch stamping, and box loading.

3. Film Binding (LYKZJ-180): Automates the sorting and wrapping of finished cartons using PE elastic film.



1. Introduction

The LYKXGF2-30 series is a high-performance integrated production line specifically engineered for the aseptic processing of 2-30ml vials. This system automates over 20 critical process steps—including ultrasonic cleaning, sterilization, nitrogen flushing, and precise filling—to ensure full compliance with the most stringent global pharmaceutical GMP standards.

2. Core Modules & Technical Advantages

This sophisticated line seamlessly integrates four primary modules to maintain a continuous, sterile workflow:

• Vertical Ultrasonic Washing Machine: Utilizes a combination of online ultrasonic cleaning and independent, alternating water and air jets. This method provides the highest cleaning efficacy and detection rates for visible foreign matter while maintaining a very low bottle breakage rate.

• Tunnel Sterilization Oven: Employs the laminar flow principle and high-speed hot air sterilization. Containers pass through a sealed tunnel under Class-A standard conditions for preheating, drying, sterilization, and cooling.

• Filling and Stoppering Machine: Features a "positive table" (balcony-style) design for easy cleaning. It uses a disk synchronous belt for stable bottle transfer and provides high-yield, high-accuracy filling and stoppering.

• Capping Machine: Utilizes a specialized small-knife side follow-up rolling principle. The adjustable blades ensure smooth rolling and a perfect seal without damaging the domestic or international packaging materials.

3. Key Technical Parameters

The LYKXGF2-30 series is designed for large-scale pharmaceutical operations:

4. Competitive Edge

• Aseptic Integrity: Equipped with independent spray needles for water and gas to avoid cross-contamination, meeting the latest "New GMP" requirements.

• Advanced Control: The line uses a simple and intuitive Human-Machine Interface (HMI) with PLC control for automated fault self-diagnosis and troubleshooting.

• Flexible Production: The modular design allows for rapid adjustment between different bottle sizes, making it ideal for both medium and large-batch manufacturing.

5. Conclusion

Suzhou Lingyao provides a "turnkey" solution that prioritizes health, low consumption, and high automation. Our vial linkage lines are ready to help global pharmaceutical manufacturers achieve first-class production quality.

1. Introduction

In modern biopharmaceutical production, the packaging process for small-volume injections (1-20ml) demands rigorous sterile environments and high efficiency. The LYAPL1-20 series linkage production line developed by Suzhou Lingyao is designed to minimize manual intervention through fully automated processes, ensuring total compliance with current national Good Manufacturing Practice (GMP) standards.

2. Core Modules & Technical Advantages

The production line consists of three key pieces of equipment, achieving a seamless transition from washing to sealing:

• Vertical Ultrasonic Washing Machine: This module combines online ultrasonic cleaning with independent, alternating water and air jets. It offers superior cleaning, a high qualified rate for foreign matter detection, and an extremely low breakage rate.

• Tunnel Sterilization Oven: Based on laminar flow principles, containers undergo preheating, sterilization, and cooling under Class-A standard laminar flow within a sealed tunnel.

• Ampoule Filling & Sealing Machine: Featuring a positive desk design, it supports nitrogen flushing before and after filling to ensure liquid stability. It provides high-quality wire-drawing sealing with stable operation.

3. Key Technical Parameters

These professional parameters highlight the technical strength of the LYAPL1-20 series:

4. Competitive Edge

• Intelligent Automation: The entire line features self-diagnostic functions and fault analysis, utilizing an intuitive HMI to achieve full automation control.

• Sustainable Innovation: Lingyao Machinery continuously optimizes processes to meet market demands for "Health, Low consumption, High efficiency, and Automation".

• Proven Global Reach: With products exported to Europe, India, Pakistan, Bangladesh, Thailand, and Russia, we provide mature turnkey solutions for international pharmaceutical plants.

5. Conclusion

Suzhou Lingyao is dedicated to providing professional products and services for the global pharmaceutical industry. If you are looking for an efficient, compliant ampoule packaging line, our expert team is ready to assist you.

1. How does your ampoule filling line ensure precision in every fill?
Our ampoule filling line uses advanced servo-driven technology and precision nozzles to ensure accurate dosing for every ampoule. This eliminates variability and ensures consistent product quality, even at high speeds.

2. Can your ampoule filling line handle different types of liquids and viscosities?
Absolutely! Our machine is designed to handle a wide range of liquids, from thin solutions to viscous formulations. Its modular design allows for easy adjustments to accommodate different product requirements.

3. What makes your ampoule filling line stand out in terms of automation?
Our ampoule filling line features fully automated operation, from ampoule feeding to sealing. This reduces manual intervention, minimizes human error, and maximizes production efficiency.

4. How does your ampoule filling line maintain sterility and compliance?
The machine is equipped with an aseptic filling system and is constructed with materials that meet GMP and FDA standards. This ensures sterility and compliance with the strictest pharmaceutical regulations.

5. Is your ampoule filling line easy to integrate into existing production lines?
Yes, our machine is designed for seamless integration. Its compact footprint and user-friendly interface make it easy to incorporate into your current setup without significant downtime.

6. What kind of long-term value does your ampoule filling line offer?
Our ampoule filling line is built for durability and low maintenance. With its high-speed operation and minimal downtime, it delivers long-term cost savings and a quick return on investment.

7. Can your ampoule filling line be customized for specific production needs?
Yes, we offer customizable solutions to meet your unique requirements, including different ampoule sizes, filling volumes, and production speeds.

8. How does your ampoule filling line handle high-speed production without compromising quality?
Our machine is engineered with precision components and advanced control systems to maintain high-speed production while ensuring consistent quality and accuracy.

9. What kind of support do you provide after installation?
We offer comprehensive support, including training, maintenance services, and 24/7 technical assistance, to ensure your ampoule filling line operates at peak performance.

10. How can I see your ampoule filling line in action?
We’d be happy to arrange a live demonstration or virtual tour of our ampoule filling line. Contact us today to schedule a session!
