Heat Sealing Machine, DuPont paper heat sealer for medical blister tray

Heat Sealing Machine, DuPont paper heat sealer for medical blister tray

Brand Name: Lingyao
Model Number: LY120A
MOQ: 1 unit
Price: USD 5,000-50,000 per unit
Payment Terms: D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 10 pcs per month
Detail Information
Place of Origin:
China(Thailand available soon)
Certification:
ISO1348-2016
Control System:
Digital
Labeling Type:
Semi Automatic
Standard:
GMP
Power Supply:
380V/50Hz
Model:
LY120A
Application:
Pharmaceutical
Material:
Stainless Steel
Power Source:
Electric
Packaging Type:
Wooden Case
Frequency:
50Hz
Sealing Speed:
0-12m/min
Sealing Length:
300mm
Temperature Range:
0-300℃
Power:
5KW
Size:
1200mm X 800mm X 1650mm
Packaging Details:
carton, wood carton, pallets
Supply Ability:
10 pcs per month
Highlight:

50Hz Medical Heat Sealer

,

Blister Tray Medical Heat Sealer

,

5KW medical pouch heat sealer

Product Description

Heat Sealing Machine, DuPont paper heat sealer for medical blister tray



The LY-120A Medical Sterile Tyvek DuPont Paper Heat Sealing Machine is a device used for sealing plastic materials such as PET, PETG, PVC, PE, PP, and card paper for medical devices.

The main body design of this equipment originates from advanced European technology and has been upgraded and improved according to customer needs during the production process. It is a technologically mature device for sealing plastic materials and card paper.

The sealed products have a crystal-clear, transparent, moisture-proof appearance with high quality.

The machine uses PLC control combined with a human-machine interface operation, with full functionality, easy operation, stable and reliable operation, and meets GMP specification requirements.

Due to the large mold area of the machine and the ability to cut multiple plates at once (standard version cuts two at a time), it meets the production needs of enterprises to a certain extent, making it especially suitable for use in medical field.



Model LY-120A
Cutting Frequency 5-25 times/min
Tooling layout according to product size
Tooling max size 500mm X 400mm
PET thickness 0.3mm-1.0mm
Dialysis Paper 50-100g x 620
Air pressure and consumption 0.6-0.8 Mpa/10-20 cbm/hour
Voltage/Frequency 220V/50Hz
Total Power 5KW
Machine Size 1200mm x 800mm x 1650mm
Weight 500 KGs



Heat Sealing Machine, DuPont paper heat sealer for medical blister tray 0Heat Sealing Machine, DuPont paper heat sealer for medical blister tray 1





The Tyvek heat sealing machine works by using heat and pressure to seal Tyvek material, which is a type of high-density polyethylene (HDPE) material made by DuPont. Here is a general overview of how a Tyvek heat sealing machine typically works:

  1. Preparation: The Tyvek material to be sealed is placed between the sealing bars of the machine.

  2. Heating: The machine heats the sealing bars to a specific temperature suitable for sealing Tyvek material. The heat softens the material, allowing it to bond together when pressure is applied.

  3. Pressure: The sealing bars come together under pressure, pressing the heated Tyvek material together to create a strong seal.

  4. Cooling: After the sealing process is complete, the sealed Tyvek material is allowed to cool down and solidify, ensuring a secure bond.

  5. Trimming: In some cases, the excess material may be trimmed off to create a clean and neat seal.

  6. Quality Check: The sealed Tyvek material may undergo a quality check to ensure that the seal is strong, secure, and meets the required specifications.

Overall, the Tyvek heat sealing machine combines heat and pressure to effectively seal Tyvek material, creating airtight and secure seals for various applications, including medical packaging, protective clothing, and other industries.
